LA1DZ40

LA1DZ40 Schneider Electric

The product image shown is for illustration purposes only and may not be an exact representation of the product. Please refer to the item description for accurate information

Please note: Some products are subject to manufacturer minimum pack quantities. We will confirm this at time of order.

Description for LA1DZ40 Schneider Electric

LA1DZ40 Schneider Electric - TeSys D - auxiliary contact block - 4 NO - screw clamp terminals

Extended Description for LA1DZ40 Schneider Electric

LA1DZ40 Schneider Electric - TeSys Deca instantaneous auxiliary contact block with dust and damp protected contacts, for LC1D contactors and CAD control relays in harsh industral environments.,It provides 2NO protected contacts rated up to 0.1A 125V AC / 30V DC, 2NO not protected contacts rated up to 10A 690V AC, connection by screw clamp terminals.,Protected contacts with very low minimum switching capacity (5V / 1mA) thanks to gold alloy contact material.,Front mounting by clip-on, it procures high reliability and durability.,Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).

Free Delivery to UK Mainland on orders over £25

Direct from Manufacturer

Available on back order
4 - 6 W.Weeks
£36.32 Exc. VAT
£43.59 Inc. VAT

Main

Range TeSys
Product name TeSys Deca
product or component type Auxiliary contact block
Device short name LA1
Range compatibility TeSys D CAD,TeSys D LC1D,TeSys F LC1F,TeSys F CR1F,TeSys Deca CAD,TeSys Deca LC1D
Mounting location Front
Pole contact composition 2 NO (sealed) + 2 NO
Contacts operation Instantaneous
[Ue] rated operational voltage 125 V AC for protected contact,30 V DC for protected contact,690 V AC for non-protected contact
[Ie] rated operational current 0.1 A for protected contact
[Ui] rated insulation voltage 250 V - for protected contact conforming to IEC 60947-5-1,690 V - for non-protected contact conforming to IEC 60947-5-1,600 V - for non-protected contact conforming to UL 60947-5-1,600 V - for non-protected contact conforming to CSA C22.2 No 60947-5-1
[Ith] conventional free air thermal current 10 A (at 40 °C) for non-protected contact
Product certifications CB,UL,CSA,CCC,EAC,UKCA

Complementary

Protection type GG fuse 10 A for non-protected contact
Mechanical durability 5 Mcycles
Minimum switching current 1 mA for protected contact,5 mA for non-protected contact
Minimum switching voltage 5 V for protected contact,17 V for non-protected contact
Insulation resistance > 10 MOhm
Connections - terminals Screw clamp terminals 1 cable(s) 1…2.5 mm²flexible with cable end,Screw clamp terminals 1 cable(s) 1…2.5 mm²flexible without cable end,Screw clamp terminals 2 cable(s) 1…2.5 mm²flexible with cable end,Screw clamp terminals 2 cable(s) 1…2.5 mm²flexible without cable end,Screw clamp terminals 1 cable(s) 1…2.5 mm²rigid,Screw clamp terminals 2 cable(s) 1…2.5 mm²rigid
Tightening torque 1.7 N.m - with screwdriver flat Ø 6 mm,1.7 N.m - with screwdriver Philips No 2,1.7 N.m - with screwdriver pozidriv No 2
Height 48 mm
Width 44 mm
Depth 39 mm
net weight 0.05 kg

Environment

Environmental characteristic Harsh environment
IP degree of protection IP2X conforming to IEC 60529
Protective treatment TH conforming to IEC 60068
Ambient air temperature for storage -25…70 °C
Ambient air temperature for operation -25…70 °C

Packing Units

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 4.700 cm
Package 1 Width 4.800 cm
Package 1 Length 5.100 cm
Package 1 Weight 64.000 g
Unit Type of Package 2 S02
Number of Units in Package 2 80
Package 2 Height 15.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 5.465 kg

Contractual warranty

Warranty 18 months
