Schneider Electric

SR2MOD01

SR2MOD01 Schneider Electric

The product image shown is for illustration purposes only and may not be an exact representation of the product. Please refer to the item description for accurate information

Please note: Some products are subject to manufacturer minimum pack quantities. We will confirm this at time of order.

Description for SR2MOD01 Schneider Electric

SR2MOD01 Schneider Electric - modem interface - analog PSTN - for communication interface SR2COM01

Extended Description for SR2MOD01 Schneider Electric

SR2MOD01 Schneider Electric - This modem interface is proposed as an accessory of Zelio Logic smart relays range.,It comprises one analogue PSTN modem and one telephone cable.,Its functions are: transfer program, send alarm/receive instruction, update firmware monitoring.

Free Delivery to UK Mainland on orders over £25

Direct from Manufacturer

Available on back order
4 - 6 W.Weeks
£557.61 Exc. VAT
£669.13 Inc. VAT

Main

range of product Modicon M251,Modicon M221,Zelio Logic,Modicon M241
product or component type Analogue PSTN modem
Type of modem SIXNET VT-MODEM-5-WW
Data backed up Flash memory

Complementary

Kit composition Analogue PSTN modem,1 telephone cable
Function available Transfer program,Update firmware monitoring,Send alarm/receive instruction,Send alarm to e-mail address
Number of messages 28
Electrical data recording Telephone/e-mail,Discrete and digital value,Date and time
[Us] rated supply voltage 12...24 V DC
Supply voltage limits 10…30 V
Maximum supply current 140 mA at 12 V,70 mA at 24 V,9600 mA
Power dissipation in W 1.7 W
Electrical connection 1 cable Com-M specific to Zelio RS232 serial, specific Zelio communication protocol for link with the modem, AT commands,1 cable Com-Z specific to Zelio, specific Zelio communication protocol for Zelio Logic smart relays SR.B..... and SR2 E..... Version (>= V3.1),Telephone cable
Cable length 2 m
Insulation 1780 V optocoupler, connector type: Com-Z specific to Zelio,By the cable SR2 CBL07, connector type: Com-M specific to Zelio
Connections - terminals Screw terminals, 1 x 0.25...1 x 2.5 mm² (AWG 24...AWG 14) flexible with cable end,Screw terminals, 2 x 0.25...2 x 0.75 mm² (AWG 24...AWG 18) flexible with cable end,Screw terminals, 1 x 0.25...1 x 2.5 mm² (AWG 24...AWG 14) semi-solid,Screw terminals, 1 x 0.25...1 x 2.5 mm² (AWG 24...AWG 14) solid,Screw terminals, 2 x 0.25...2 x 1.5 mm² (AWG 23...AWG 16) solid
Tightening torque 0.5 N.m
net weight 0.265 kg

Environment

Product certifications FCC part 15 standard,C-Tick,ACA TS,CTR21,GOST,UL,AS/NZS,CSA
Standards EN/IEC 60068-2-27 Ea,EN/IEC 61000-4-5,EN/IEC 60068-2-6 Fc
Electromagnetic compatibility Conducted and radiated emissions class B group 1 conforming to EN 55022-11
IP degree of protection IP20 (terminal block) conforming to IEC 60529,IP40 (front panel) conforming to IEC 60529
Environmental characteristic EMC directive conforming to EN/IEC 61000-6-2,EMC directive conforming to EN/IEC 61000-6-3,EMC directive conforming to EN/IEC 61000-6-4,EMC directive conforming to EN/IEC 61131-2 zone B,Low voltage directive conforming to EN/IEC 61131-2
Pollution degree 2 conforming to EN/IEC 61131-2
Ambient air temperature for operation -30…70 °C
Ambient air temperature for storage -40…85 °C
Operating altitude 2000 m
Maximum altitude transport 3048 m
Relative humidity 5…95 % without condensation

Packing Units

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 6 cm
Package 1 Width 14.5 cm
Package 1 Length 15.3 cm
Package 1 Weight 262 g

Contractual warranty

Warranty 18 months

Documentation

Product Datasheet

User guide

Instruction sheet

Catalogue

Environmental disclosure
