Schneider Electric

VZ1L018UM20

VZ1L018UM20 Schneider Electric

The product image shown is for illustration purposes only and may not be an exact representation of the product. Please refer to the item description for accurate information

Please note: Some products are subject to manufacturer minimum pack quantities. We will confirm this at time of order.

Description for VZ1L018UM20 Schneider Electric

VZ1L018UM20 Schneider Electric - line choke - 2 mH - 18 A - 1 phase - 30 W - for variable speed drive

Extended Description for VZ1L018UM20 Schneider Electric

VZ1L018UM20 Schneider Electric - This line choke can be used to provide improved protection against overvoltages on the line supply.,It can also be used to reduce harmonic distortion of the current produced by the drive.,This product is compliant with IEC 61800-5-1 (VDE 0160 level 1 high-energy overvoltages on the line supply).,Its rated current is equal to 18A and its value of inductance to 2mH.,It is compatible with Altivar 31, Altivar 32, Altivar 312, Altivar machine ATV320, Lexium 05 and Lexium 32.

Free Delivery to UK Mainland on orders over £25

Direct from Manufacturer

Available on back order
4 - 6 W.Weeks
£93.59 Exc. VAT
£112.31 Inc. VAT

Main

range of product Altivar
product or component type Line choke
Product compatibility ATV312HU11M2 - line choke - 1 per drive,ATV312HU15M2 - line choke - 1 per drive,ATV312HU22M2 - line choke - 1 per drive,ATV31CU11M2 - line choke - 1 per drive,ATV31CU15M2 - line choke - 1 per drive,ATV31CU22M2 - line choke - 1 per drive,ATV32HU11M2 - line choke - 1 per drive,ATV32HU15M2 - line choke - 1 per drive,ATV32HU22M2 - line choke - 1 per drive,LXM05D17F1 - line choke - 1 per drive,LXM05D17M2 - line choke - 1 per drive,LXM05D28F1 - line choke - 1 per drive,LXM05D28M2 - line choke - 1 per drive,LXM32.D18M2 - line choke - 1 per drive,LXM32.D30M2 - line choke - 1 per drive,LXM32.U90M2 - line choke - 1 per drive,Variable speed drive ATV320 motor: 1.1 kW 200...240 V - single phase - line choke - 1 per drive,Variable speed drive ATV320 motor: 1.5 kW 200...240 V - single phase - line choke - 1 per drive,Variable speed drive ATV320 motor: 2.2 kW 200...240 V - single phase - line choke - 1 per drive
number of phases Single phase
Range compatibility Altivar 312 Solar,Lexium 32,Altivar 312,Altivar 31C,Lexium 05,Altivar Machine ATV320,Altivar 32
device application Reduction of current harmonics
Value of inductance 2 mH
[In] rated current 18 A
Thermal losses 30 W

Complementary

power supply frequency 50...60 Hz
Maximum voltage drop at rated load 5 %
net weight 1.99 kg
Width 85 mm
Height 120 mm
Depth 105 mm

Environment

Standards VDE 0160 level 1,IEC 60076 (with HD398),EN 50178
IP degree of protection Choke: IP00,Terminals: IP20

Packing Units

Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 20.000 cm
Package 1 Width 15.000 cm
Package 1 Length 15.000 cm
Package 1 Weight 1.928 kg
Unit Type of Package 2 P06
Number of Units in Package 2 45
Package 2 Height 75.000 cm
Package 2 Width 60.000 cm
Package 2 Length 80.000 cm
Package 2 Weight 99.760 kg

Contractual warranty

Warranty 18 months

Documentation

Product Datasheet

Instruction sheet

Catalogue
