Siemens

1PH8284-1DZ13-9BU1K3SN4B

1PH8284-1DZ13-9BU1K3SN4B Siemens

The product image shown is for illustration purposes only and may not be an exact representation of the product. Please refer to the item description for accurate information

Please note: Some products are subject to manufacturer minimum pack quantities. We will confirm this at time of order.

Description for 1PH8284-1DZ13-9BU1K3SN4B Siemens

1PH8284-1DZ13-9BU1K3SN4B Siemens - SIMOTICS M compact asynchronous motor 1150 r/min, 170 kW, 1414 Nm, 310 A, 400 V forced ventilation IP55 degree of protection incremental encoder 22-bit with DRIVE-CLiQ interface type of construction IM B35 with flange A660 (IM V35) bearing version: standard vibration class: R/A; shaft and flange accuracy: R terminal box NDE right cable entry at bottom signal port DE K3S: D winding with reduced max. torque; N4B: special shaft extension d80x170 mm, with feather key half-key balancing, customer- specific motor according to SMR-65-2016

Free Delivery to UK Mainland on orders over £25

Product

Article Number (Market Facing Number) 1PH8284-1DZ13-9BU1K3SN4B
Product Description SIMOTICS M compact asynchronous motor 1150 r/min, 170 kW, 1414 Nm, 310 A, 400 V forced ventilation IP55 degree of protection incremental encoder 22-bit with DRIVE-CLiQ interface type of construction IM B35 with flange A660 (IM V35) bearing version: standard vibration class: R/A; shaft and flange accuracy: R terminal box NDE right cable entry at bottom signal port DE K3S: D winding with reduced max. torque; N4B: special shaft extension d80x170 mm, with feather key half-key balancing, customer- specific motor according to SMR-65-2016
Product family Ordering Data Overview
Product Lifecycle (PLM) PM300:Active Product

Delivery information

Export Control Regulations AL : N / ECCN : N
Estimated dispatch time (Working Days) 45 Day/Days
Net Weight (kg) 1200,000 Kg
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1

Additional Product Information

EAN Not available
UPC Not available
Commodity Code 85015381
LKZ_FDB/ CatalogID SD.NC62ST-1PH8
Product Group 9694
Group Code R220
Country of origin Czech Republic
Compliance with the substance restrictions according to RoHS directive Since: 05.11.2018
Product class D: products made to order / customer's specifications, requiring engineering services, which cannot be re-used or utilized (design to customer)
WEEE (2012/19/EU) Take-Back Obligation Yes
REACH Art. 33 Duty to inform according to the current list of candidates Reach Information Information according REACh Article 33(1) on svhc candidate substances (substances of very high concern http://echa.europa.eu/web/guest/candidate-list-table) for configured products will be provided with the order confirmation and bill of delivery. Information is available only if a duty to inform for the configured product applies.
SCIP number
