Siemens

6AG1021-0AD12-2CA2

6AG1021-0AD12-2CA2 Siemens

The product image shown is for illustration purposes only and may not be an exact representation of the product. Please refer to the item description for accurate information

Please note: Some products are subject to manufacturer minimum pack quantities. We will confirm this at time of order.

Description for 6AG1021-0AD12-2CA2 Siemens

6AG1021-0AD12-2CA2 Siemens - SIPLUS IPC 127E based on 6AG4021-0AD12-2CA0 with conformal coating, -25…+55 °C, SIMATIC IPC127E, without mounting accessories, Atom E390 (4C/4T), 4 GB RAM, with TPM, extended version, 3x Ethernet, RJ45, 4x USB 3.0, Windows 10 Enterprise 2019, LTSC, 64-bit, MUI (en,de,fr,it,es), 128 GB SSD,

Free Delivery to UK Mainland on orders over £25

Product

Article Number (Market Facing Number) 6AG1021-0AD12-2CA2
Product Description SIPLUS IPC 127E based on 6AG4021-0AD12-2CA0 with conformal coating, -25…+55 °C, SIMATIC IPC127E, without mounting accessories, Atom E390 (4C/4T), 4 GB RAM, with TPM, extended version, 3x Ethernet, RJ45, 4x USB 3.0, Windows 10 Enterprise 2019, LTSC, 64-bit, MUI (en,de,fr,it,es), 128 GB SSD,
Product family SIPLUS IPC127E
Product Lifecycle (PLM) PM300:Active Product

Delivery information

Export Control Regulations AL : N / ECCN : 5A992
Estimated dispatch time (Working Days) 45 Day/Days
Net Weight (kg) 0,720 Kg
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1

Additional Product Information

EAN 4047618129903
UPC Not available
Commodity Code 84715000
LKZ_FDB/ CatalogID A&DSE/SIP ADD
Product Group 4B99
Group Code R151
Country of origin Germany
Compliance with the substance restrictions according to RoHS directive Since: 11.12.2012
Product class C: products manufactured / produced to order, which cannot be reused or re-utilised or be returned against credit.
WEEE (2012/19/EU) Take-Back Obligation Yes
REACH Art. 33 Duty to inform according to the current list of candidates Reach Information There is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern. We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly.
SCIP number

Supply Voltage

Type Of Supply Voltage 24 V Dc
Mains Buffering
Mains/Voltage Failure Stored Energy Time 5 Ms
Processor
Processor Type Intel Atom E3940
Chipset Soc
Graphic
Graphics Controller Integrated
Drives
Ssd Yes; 128 Gb
Memory
Type Of Memory Ddr4 Onboard
Main Memory 4 Gb Ram
Capacity Of Main Memory, Max. 4 Gbyte
Interfaces
Number Of Industrial Ethernet Interfaces 3
Usb Port 4X Usb 3.0
Connection For Keyboard/Mouse Usb / Usb
Video Interfaces
Graphics Interface 1X Displayport
Industrial Ethernet
Industrial Ethernet Interface 3X Ethernet (Rj45)
— 100 Mbps Yes
— 1000 Mbps Yes
Protocols
Protocols (Ethernet)
Tcp/Ip Yes
Integrated Functions
Monitoring Functions
Temperature Monitoring Yes
Watchdog Yes
Status Leds 1X Power, 3X User
Fan No
Monitoring Function Via Network Optional
Emc
Interference Immunity Against Discharge Of Static Electricity
Interference Immunity Against Discharge Of Static
Electricity±6 Kv Contact Discharge Acc. To Iec 61000-4-2; ±8 Kv Air Discharge Acc. To Iec
61000-4-2
Interference Immunity Against High-Frequency Electromagnetic Fields
Interference Immunity Against High Frequency Radiation 10 V/M, 80 Mhz To 2 Ghz, 80 % Am Acc. To Iec 61000-4-3; 3 V/M, 2 Ghz To
2.7 Ghz, 80 % Am Acc. To Iec 61000-4-3; 10 V, 10 Khz To 80 Mhz, 80 % Am
Acc. To Iec 61000-4-6
Interference Immunity To Cable-Borne Interference
Interference Immunity On Supply Cables ±2 Kv (According To Iec 61000-4-4; Burst); ±0,5 Kv (According To Iec 61000-4-
5; Surge Pulse/Line To Line); ±1 Kv (According To Iec 61000-4-5; Surge Pulse/Line
To Ground)
Interference Immunity On Signal Cables >30M ±2 Kv Acc. To Iec 61000-4-5, Surge, Length > 30 M
Interference Immunity On Signal Cables < 30M ±1 Kv Acc. To Iec 61000-4-4; Burst; Length < 3 M; ±2 Kv Acc. To Iec 61000-4-4;
Burst; Length > 3 M
Interference Immunity Against Voltage Surge
Asymmetric Interference ±2 Kv Acc. To Iec 61000-4-5, Surge Asymmetric
Symmetric Interference ±1 Kv Acc. To Iec 61000-4-5, Surge Symmetric
Interference Immunity To Magnetic Fields
Interference Immunity To Magnetic Fields At 50 Hz 100 A/M; To Iec 61000-4-8
Emission Of Conducted And Non-Conducted Interference
Interference Emission Via Line/Ac Current Cables En 61000-6-4:2007 +A1:2011 (Industrial Environments), En 61000-6-3:2007
+A1:2011 (Residential Environments), Cispr 22 Class B, Fcc Class A
Degree And Class Of Protection
Ip Degree Of Protection Ip40
Standards, Approvals, Certificates
Dust Protection Protection Against Foreign Bodies > 1 Mm

Ambient Temperature During Operation

Min. -25 °C; = Tmin (Incl. Condensation/Frost)
Max. 55 °C; = Tmax With Standard Mounting Position
Ambient Temperature During Storage/Transportation
Min. -40 °C
Max. 70 °C
Altitude During Operation Relating To Sea Level
Installation Altitude Above Sea Level, Max. 3 500 M
Ambient Air Temperature-Barometric Pressure-Altitude Tmin ... Tmax At 1 080 Hpa ... 660 Hpa (-1 000 M ... +3 500 M)
Relative Humidity
With Condensation, Tested In Accordance With Iec 60068-
2-38, Max.100 %; Rh Incl. Condensation/Frost (No Commissioning When Condensation Is
Present), Standard Mounting Position
Vibrations
Vibration Resistance During Operation Acc. To Iec 60068-
2-6Tested According To Iec 6068-2-6; 5 Hz To 9 Hz: 3.5 Mm, 9 Hz To 500 Hz: 9,8
M/S²
Shock Testing
Shock Load During Operation Tested According To Iec 60068-2-27: 150 M/S², 11 Ms
Resistance
Coolants And Lubricants
— Resistant To Commercially Available Coolants And
Lubricantsyes; Incl. Diesel And Oil Droplets In The Air
Use In Stationary Industrial Systems
— To Biologically Active Substances According To En
60721-3-3Yes; Class 3B2 Mold, Fungus And Dry Rot Spores (With The Exception Of Fauna);
Class 3B3 On Request
— To Chemically Active Substances According To En
60721-3-3Yes; Class 3C4 (Rh < 75 %) Incl. Salt Spray Acc. To En 60068-2-52 (Severity
Degree 3); *
— To Mechanically Active Substances According To En
60721-3-3Yes; Class 3S4 Incl. Sand, Dust, *
Use On Ships/At Sea
— To Biologically Active Substances According To En
60721-3-6Yes; Class 6B2 Mold, Fungal And Dry Rot Spores (Excluding Fauna)
— To Chemically Active Substances According To En
60721-3-6Yes; Class 6C3 (Rh < 75 %) Incl. Salt Spray Acc. To En 60068-2-52 (Severity
Degree 3); *
— To Mechanically Active Substances According To En
60721-3-6Yes; Class 6S3 Incl. Sand, Dust; *
Usage In Industrial Process Technology
— Against Chemically Active Substances Acc. To En
60654-4Yes; Class 3 (Excluding Trichlorethylene)
— Environmental Conditions For Process, Measuring
And Control Systems Acc. To Ansi/Isa-71.04Yes; Level Gx Group A/B (Excluding Trichlorethylene; Harmful Gas
Concentrations Up To The Limits Of En 60721-3-3 Class 3C4 Permissible); Level
Lc3 (Salt Spray) And Level Lb3 (Oil)
Remark
— Note Regarding Classification Of Environmental
Conditions Acc. To En 60721, En 60654-4 And
Ansi/Isa-71.04* The Supplied Plug Covers Must Remain In Place Over The Unused Interfaces
During Operation!
Conformal Coating
Coatings For Printed Circuit Board Assemblies Acc. To En Yes; Class 2 For High Reliability
61086
Protection Against Fouling Acc. To En 60664-3 Yes; Type 1 Protection
Military Testing According To Mil-I-46058C, Amendment 7 Yes; Discoloration Of Coating Possible During Service Life
Qualification And Performance Of Electrical Insulating
Compound For Printed Board Assemblies According To Ipc-
Cc-830Ayes; Conformal Coating, Class A

Operating Systems

Pre-Installed Operating System Windows 10 Enterprise Ltsc 2019, 64Bits, Mui
Without Operating System Yes; Optional
Pre-Installed Operating System
Windows 10 Enterprise Yes; Windows 10 Iot Enterprise 2019 Ltsc, 64 Bit, Mui
