Siemens

6AG4141-5BC30-0FW8

6AG4141-5BC30-0FW8 Siemens

The product image shown is for illustration purposes only and may not be an exact representation of the product. Please refer to the item description for accurate information

Please note: Some products are subject to manufacturer minimum pack quantities. We will confirm this at time of order.

Description for 6AG4141-5BC30-0FW8 Siemens

6AG4141-5BC30-0FW8 Siemens - SIMATIC IPC427E (Microbox PC), HD graphic onboard, 4x USB V3.0 (high current), PCIe (optional), Core i5-6442EQ; 3x Gbit Ethernet (IE/PN); mounting onto standard rail; 16 GB; 2x RS232/485; without PCIe; without operating system, without exchangeable mass storage; 240 GB solid-state drive SATA; Industrial Edge – SIMATIC; 24 V DC industrial power supply and TPM

Free Delivery to UK Mainland on orders over £25

Product

Article Number (Market Facing Number) 6AG4141-5BC30-0FW8
Product Description SIMATIC IPC427E (Microbox PC), HD graphic onboard, 4x USB V3.0 (high current), PCIe (optional), Core i5-6442EQ; 3x Gbit Ethernet (IE/PN); mounting onto standard rail; 16 GB; 2x RS232/485; without PCIe; without operating system, without exchangeable mass storage; 240 GB solid-state drive SATA; Industrial Edge – SIMATIC; 24 V DC industrial power supply and TPM
Product family SIMATIC IPC427E
Product Lifecycle (PLM) PM300:Active Product

Delivery information

Export Control Regulations AL : N / ECCN : 5A992
Estimated dispatch time (Working Days) 15 Day/Days
Net Weight (kg) 2,723 Kg
Packaging Dimension 23,30 x 35,10 x 16,40
Package size unit of measure CM
Quantity Unit 1 Piece
Packaging Quantity 1

Additional Product Information

EAN 4047622931806
UPC 195125272910
Commodity Code 84715000
LKZ_FDB/ CatalogID IC10
Product Group 2378
Group Code R133
Country of origin Germany
Compliance with the substance restrictions according to RoHS directive Since: 29.03.2021
Product class A: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back Obligation Yes
REACH Art. 33 Duty to inform according to the current list of candidates Reach Information There is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern. We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly.
SCIP number

Supply Voltage

Type Of Supply Voltage 24 V Dc
Mains Buffering
Mains/Voltage Failure Stored Energy Time 20 Ms
Processor
Processor Type Core I5-6442Eq (4C/4T, 1.9 (2.7) Ghz, 6 Mb Cache)
Chipset Intel C236 / Intel H110
Graphic
Graphics Controller Intel Hd Graphics Controller
Drives
Ssd Yes; ≥ 240 Gb Optional
Memory
Type Of Memory Ddr4-2400 So-Dimm
Capacity Of Main Memory, Max. 16 Gbyte
Hardware Configuration
Slots
Number Of Pci Slots 0
Number Of Compact Flash Slots 1; Cfast
Interfaces
Number Of Industrial Ethernet Interfaces 3; Ethernet (2X Rj45, Optional 3X Rj45)
Usb Port 4X Usb 3.0
Connection For Keyboard/Mouse Usb / Usb
Serial Interface 2X Com (1X Rs 232; 1X Rs 232 / 422 / 485)
Video Interfaces
Graphics Interface 2X Displayport
Industrial Ethernet
Industrial Ethernet Interface 3X Ethernet (Rj45)
— 100 Mbps Yes
— 1000 Mbps Yes
Interrupts/Diagnostics/Status Information
Bus Diagnostics Yes
Integrated Functions
Monitoring Functions
Temperature Monitoring Yes
Watchdog Yes
Status Leds 1X Power, 3X User
Fan No
Monitoring Function Via Network Optional
Emc
Interference Immunity Against Discharge Of Static Electricity
Interference Immunity Against Discharge Of Static
Electricity±6 Kv Contact Discharge Acc. To Iec 61000-4-2; ±8 Kv Air Discharge Acc. To Iec
61000-4-2
Interference Immunity Against High-Frequency Electromagnetic Fields
Interference Immunity Against High Frequency Radiation 10 V/M For 80 - 1 000 Mhz And 1.4 - 2 Ghz, 80% Am Acc. To Iec 61000-4-3; 3
V/M For 2 - 2.7 Ghz, 80% Am Acc. To Iec 61000-4-3; 10 V For 10 Khz - 80 Mhz,
80% Am Acc. To Iec 61000-4-6
Interference Immunity To Cable-Borne Interference
Interference Immunity On Supply Cables ±2 Kv Acc. To Iec 61000-4-4, Burst; ±1 Kv Acc. To Iec 61000-4-5, Surge
Symmetric; ±2 Kv Acc. To Iec 61000-4-5, Surge Asymmetric
Interference Immunity On Signal Cables >30M ±2 Kv Acc. To Iec 61000-4-5, Surge, Length > 30 M
Interference Immunity On Signal Cables < 30M ±1 Kv Acc. To Iec 61000-4-4; Burst; Length < 3 M; ±2 Kv Acc. To Iec 61000-4-4;
Burst; Length > 3 M
Interference Immunity Against Voltage Surge
Asymmetric Interference ±2 Kv Acc. To Iec 61000-4-5, Surge Asymmetric
Symmetric Interference ±1 Kv Acc. To Iec 61000-4-5, Surge Symmetric
Interference Immunity To Magnetic Fields
Interference Immunity To Magnetic Fields At 50 Hz 100 A/M; To Iec 61000-4-8
Emission Of Conducted And Non-Conducted Interference
Interference Emission Via Line/Ac Current Cables En 61000-6-3, En 61000-6-4, Cispr 22 Class B, Fcc Class A
Degree And Class Of Protection
Ip Degree Of Protection Ip20
Standards, Approvals, Certificates
Ce Mark Yes
Ul Approval Yes
Ul 508 Yes
Culus Yes
Rcm (Formerly C-Tick) Yes
Kc Approval Yes
Eac (Formerly Gost-R) Yes
Fcc Yes
Emc Ce, En 55022A, En 61000-6-4, En 61000-6-2
Use In Hazardous Areas
Atex Zone 2 Yes; Optional
Iecex Zone 2 Yes; Optional
Culus Class I Zone 2, Division 2 Yes; Optional
Marine Approval
Germanischer Lloyd (Gl) Yes
American Bureau Of Shipping (Abs) Yes
Bureau Veritas (Bv) Yes
Det Norske Veritas (Dnv) Yes
Korean Register Of Shipping (Krs) Yes
Lloyds Register Of Shipping (Lrs) Yes
Nippon Kaiji Kyokai (Class Nk) Yes

Ambient Temperature During Operation

Min. 0 °C
Max. 55 °C
Ambient Temperature During Storage/Transportation
Min. -40 °C
Max. 70 °C
Relative Humidity
Relative Humidity Tested According To Iec 60068-2-78, Iec 60068-2-30: Operation: 5% To 80% At
25 °C (No Condensation), Storage: 5% To 95% At 25 °C (No Condensation)
Vibrations
Vibration Resistance During Operation Acc. To Iec 60068-
2-6Tested To Din Iec 60068-2-6: 10 Hz To 58 Hz: 0.075 Mm, 58 Hz To 200 Hz: 9.8
M/S² (1 G)
Shock Testing
Shock Load During Operation Tested To Din Iec 60068-2-29: 50 M/S² (5 G), 30 Ms, 100 Shocks

Operating Systems

Pre-Installed Operating System Simatic Industrial Os
Software
Simatic Software Industrial Edge - Simatic

Dimensions

Width 262 Mm
Height 139.7 Mm
Depth 55.5 Mm; Without Pcie
