Siemens

6GT2800-5BB00

6GT2800-5BB00 Siemens

The product image shown is for illustration purposes only and may not be an exact representation of the product. Please refer to the item description for accurate information

Please note: Some products are subject to manufacturer minimum pack quantities. We will confirm this at time of order.

Description for 6GT2800-5BB00 Siemens

6GT2800-5BB00 Siemens - SIMATIC RF300 Transponder RF340T 32 KB FRAM, IP67/X9K, -25 to +85 °C, 48x25x 15 mm, minimum order quantity 5 units.

Free Delivery to UK Mainland on orders over £25

Product

Article Number (Market Facing Number) 6GT2800-5BB00
Product Description SIMATIC RF300 Transponder RF340T 32 KB FRAM, IP67/X9K, -25 to +85 °C, 48x25x 15 mm, minimum order quantity 5 units.
Product family RF340T
Product Lifecycle (PLM) PM300:Active Product

Delivery information

Export Control Regulations AL : N / ECCN : N
Estimated dispatch time (Working Days) 1 Day/Days
Net Weight (kg) 0,025 Kg
Packaging Dimension 90,00 x 30,00 x 0,20
Package size unit of measure MM
Quantity Unit 1 Piece
Packaging Quantity 1
Minimum order quantity 5

Additional Product Information

EAN 4047618052805
UPC 804766234729
Commodity Code 85235200
LKZ_FDB/ CatalogID ID10.M
Product Group 9471
Group Code R322
Country of origin Germany
Compliance with the substance restrictions according to RoHS directive Given
Product class A: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back Obligation Yes
REACH Art. 33 Duty to inform according to the current list of candidates Lead CAS-No. 7439-92-1 > 0, 1 % (w / w) Information obligation imposed by Article 33, REACH Regulation: This product includes one or several articles in which the following substance of the candidate list is contained in concentrations higher than 0,1% weight by weight (w/w): Lead Based on the information currently available, we assume that these substances do not pose any risk if the articles are used as intended (including disposal). Please also refer to product documentation.
SCIP number

Electrical Data

Product Component / Backup Battery No
Memory
Type Of Memory Fram / Eeprom
Storage Capacity / Of The User Memory 32765 Byte
Type Of Memory Organization Uid (Fixed Code) 4 Bytes, User Memory 32765 Bytes, Otp Memory 20 Bytes
Number Of Read Cycles / At Ambient Temperature < 40 °C /
Maximum 1E+10
Number Of Write Cycles / At Ambient Temperature < 40 °C /
Maximum 1E+10
Data Retention Time / At Ambient Temperature < 40 °C / Not Less
Than10 A
Property Of Memory Block-By-Block Write Protection Of The Otp Memory

Mechanical Data

Material Pa12
Color Anthracite
Mounting Distance / Relating To Metal Surfaces / Recommended /
Minimum 0 Mm

Ambient Conditions

Ambient Temperature
During Read/Write Access -25 ... +85 °C
Outside The Read/Write Area -40 ... +85 °C
During Storage -40 ... +85 °C
Protection Class Ip Ip67/Ipx9K
Shock Resistance According To Din En 60721-3-7 Class 7 M3
Shock Acceleration 500 M/S²
Vibrational Acceleration 200 M/S²
Design, Dimensions And Weights
Width 25 Mm
Height 15 Mm
Depth 48 Mm
Net Weight 25 G
Fastening Method 2 X M3 Screws

Product Features, Product Functions, Product Components / General

Product Feature
Silicon-Free Yes
Printable No

Standards, Specifications, Approvals

Certificate Of Suitability
Iecex No
Culus Approval Yes
Mtbf 1200 A
Reference Code
According To Iec 81346-2:2019 Cfa
Standards, Specifications, Approvals / Environmental Product Declaration
Environmental Product Declaration Yes
Global Warming Potential [Co2 Eq]
Total 0.93 Kg
During Manufacturing 0.88 Kg
During Operation 0.00041 Kg
After End Of Life 0.05 Kg
