Siemens

7SJ6615-5EB92-1FA0 L0D

7SJ6615-5EB92-1FA0 L0D Siemens

The product image shown is for illustration purposes only and may not be an exact representation of the product. Please refer to the item description for accurate information

Please note: Some products are subject to manufacturer minimum pack quantities. We will confirm this at time of order.

Description for 7SJ6615-5EB92-1FA0 L0D Siemens

7SJ6615-5EB92-1FA0 L0D Siemens - MULTIFUNCTION PROTECTIVE RELAY CASE 1/3 19", 4 X U, 4 X I, 16BI, 7BO,1 LIVE-STATUS CONTACT MEASURING INPUTS: IPH = 5A, IN = 5A (MIN.= 0.25A) SUPPLY VOLTAGE: 110 TO 250V DC,115 TO 230V AC TRIGG.LEVEL BINARY INPUT DC 69V FLUSH MOUNTING CASE, SPRING TYPE TERMINALS LANGUAGE: ENGLISH, 50/60HZ SYSTEM PORT: MODBUS RS485 SERVICE PORT: DIGSI 4 / MODEM /RTD-BOX, ELECTRICAL RS485 MEASURING: FAULT RECORDING FUNCTIONALITY: BASIC VERSION WITHOUT AUTO-RECLOSURE WITHOUT FAULT LOCATOR WITHOUT SYNCHRONIZATION

Free Delivery to UK Mainland on orders over £25

Product

Article Number (Market Facing Number) 7SJ6615-5EB92-1FA0 L0D
Product Description MULTIFUNCTION PROTECTIVE RELAY CASE 1/3 19", 4 X U, 4 X I, 16BI, 7BO,1 LIVE-STATUS CONTACT MEASURING INPUTS: IPH = 5A, IN = 5A (MIN.= 0.25A) SUPPLY VOLTAGE: 110 TO 250V DC,115 TO 230V AC TRIGG.LEVEL BINARY INPUT DC 69V FLUSH MOUNTING CASE, SPRING TYPE TERMINALS LANGUAGE: ENGLISH, 50/60HZ SYSTEM PORT: MODBUS RS485 SERVICE PORT: DIGSI 4 / MODEM /RTD-BOX, ELECTRICAL RS485 MEASURING: FAULT RECORDING FUNCTIONALITY: BASIC VERSION WITHOUT AUTO-RECLOSURE WITHOUT FAULT LOCATOR WITHOUT SYNCHRONIZATION
Product family SIPROTEC 7SJ66 - 4xI 4xV, 8 line or graphical display, directional
Product Lifecycle (PLM) PM300:Active Product

Delivery information

Export Control Regulations AL : N / ECCN : EAR99
Estimated dispatch time (Working Days) 20 Day/Days
Net Weight (kg) 5,100 Kg
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1

Additional Product Information

EAN Not available
UPC Not available
Commodity Code 85363010
LKZ_FDB/ CatalogID SIPROTEC
Product Group 1319
Group Code U321
Country of origin India
Compliance with the substance restrictions according to RoHS directive Since: 25.04.2014
Product class B: return restricted, please contact your Siemens partner/contact
WEEE (2012/19/EU) Take-Back Obligation Yes
REACH Art. 33 Duty to inform according to the current list of candidates Reach Information There is currently no information on SVHC (Substances of Very High Concern http://echa.europa.eu/web/guest/candidate-list-table) from the supply chain and our established procedures for screening our products for Substances of Very High Concern. We compare our products regularly with the information of the upstream users with regard to the substances indicated in the candidate list in accordance with the requirements of the REACH regulation. As soon as we have new findings, our information will be updated accordingly.
SCIP number
